Description Navistar Diamond Logic Builder (DLB) provides high-performance diagnostics for the electrical systems on International trucks and IC Buses.DLB intuitively displayed in the form of graphics and text. This software reads and displays vehicle trouble codes as well as vehicle features and parameters. Note:After payment,the download link will show on page,if you can not get it,pls contact on Whatsapp or [email protected] International Diamond Logic Builder DLB Features: Level:Level 3 Date: 04.2024/10.2025 Size:About 440MB rar Region: Worldwide Language:English Only Database Version:425/488 OS Requires:Win7,Win8 and Win10 Price only for ONE PC Installation and Activation Diamond Logic Builder DLB 2024.04 Video Demo: International Diamond Logic Builder DLB Level Information: Level 1 (Diagnostics)-L1 is included with active product key. Level 2 (Diagnostics and Parameter Programming)-L2 access requires completion of web based training for each user. Level 3 (Diagnostics, Parameter Programming and Advanced Logic)-L3 access NOT requires completion of Instructor Led training for each user. International Diamond Logic Builder DLB Functions: Automatic vehicle identification Read, clear DTC codes Data List Graphical Actuation test View ECU Information Advanced Features: Change the switch position Change and edit option on the body system (off /on cruise control, change the action modes of the lights, Adjust door lock according to vehicle speed …) Control of the control system Watch Record Save Play instant recordings Problem diagnosis codes Retrieve, View, Delete HD-OBD Freeze Frame Data HD-OBD monitors Monitor the results Preparation for diagnosis Monitor the performance ratio View, save print Service Bay Tests key on, engine off Actuator tests Intermittent fault sensor Cold start test Engine running Air management test Cylinder cutting test Engine fan test (if equipped) High pressure pump test Post-treatment system tests Procedures Calibration of the sensor Replacements of parts Programmable parameters Motor characteristics settings See Programming Change Programming Restoration of the service interval International Diamond Logic Builder DLB Supports Models: MaxxForce 5 (2007 – 2009) MaxxForce 7 (2007 – 2009) MaxxForce 7 (2010 – 2012) MaxxForce 7 (2013 – ) MaxxForce DT, 9 & 10 (2007 – 2009) MaxxForce DT, 9 & 10 (2010 – 2012) MaxxForce DT, 9 & 10 (2013) MaxxForce 11/13 (2008 – 2009) MaxxForce 11/13 (2010 – 2012) MaxxForce 11/13 (2013 – 2013.5) MaxxForce 15 (2010 – 2013) N9/N10 SCR (2014 – ) N13 SCR (2013 – 2014) N13 SCR (2015 – ) International Diamond Logic Builder DLB Compatible Interface: Nexiq USB link (version 1 or 2) DPA5 Noregon DLA And some other RP1210 devices International Diamond Logic Builder DLB Master List: ABS_Active_Event ABS_Drive_Axle_Event_Raw_Signal ABS_Drive_Axle_Event_Signal ABS_Failure_Event ABS_Hyd_Warning_Lamp_Raw_Signal ABS_Hyd_Warning_Lamp_Signal ABS_Warning_Lamp Acc_Fault Accessory_Global_Signal Actual_Retarder_Percent_Torque J1939BB_Rcv_61217_058_033_Timer ADR35_Signal Air_Horn_J1939_Status Air_Horn_SW_Signal Axle_Load_Front_Old_Signal Engine_Speed_Function_1 Air_Solenoid_Power Air_Solenoid_Power_FET_Status Air_Solenoid_Power_Off_Req Air_Solenoid_Power_Req Air_Susp_Press_Cmd Air_Susp_Sensor_Signal Alert_Timer ASM_Swch1_Switch ASM_Swch1_Switch_Ind_Cmd ASM_Swch2_Switch ASM_Swch2_Switch_Ind_Cmd ASM_Swch3_Switch ……
